Product Detail

CONSTANT CLIMATE CHAMBER

Model: HPP 260eco

Brand: MEMMERT – Germany

• Volume: 256 liters
• Internal dimensions: 640 x 800 x 500 mm
• External dimensions: 824 x 1183 x 655 mm
• Set temperature range: 0 to 70oC
• Setting accuracy: 0.1oC
• Usage temperature range: +5 to 70oC
• Humidity setting range: 10 to 90% RH
• Setting Accuracy: 0.5% RH
• ControlCOCKPIT control panel: two displays. Multi-function PID microprocessor controller with two high-resolution TFT color displays
• Adjust parameters: temperature (oC or oF), humidity, program time, time zone
• Countdown timer is adjustable from 1 minute to 99 days
• Uses 2 DIN Class A Pt100 temperature probes to display operating temperature and alarms
• Heat balance function HeatBALANCE is used to adjust the heating level so that the balance between the top and bottom of the drying chamber, adjustable -50% to +50%
• The ControlCOCKPIT control panel has a USB port for downloading programs, reading values, and activating the indicator setting function for the user.
• Display of saved data on ControlCOCKPIT control panel (up to 10000 values equivalent in about 1 week)
• Integrated fault diagnosis for temperature and humidity control
• Connection: Ethernet LAN, USB
• Alerts: visual and audible
• Temperature control: monitor over and under temperature set by TWW, protection class 3.3 or adjust TWB temperature limiter protection class 2 selected on the display.
• Stainless steel shell construction, scratch resistant, hard and durable, galvanized steel back
• The door: fully insulated stainless steel door with 2 locking points, inner glass door, double door
• Memory capable of storing at least 10 years
• Installation languages on the ControlCOCKPIT control panel: German, English, French, Spanish, Polish, Czech, Hungarian
• SetpointWAIT function: time is activated when the temperature reaches the set temperature
• Calibration: freely selectable 3 points for each temperature and humidity value
• Programs are stored in case of a power failure
• Provide moisture with distilled water in an external container via a self-priming pump
• Humidification with a heater
• Dehumidification by cold trap using Peltier technology
• Energy-saving Peltier heating/cooling system is located behind the cabinet
• 100% air safety (100% AtmoSAFE)
• Power supply: 230V, 50/60 Hz
• Power: 700 W
